With the technology development and combined with different CNC machines, we are capable of creating different engineering parts for different industries.

But one of the main factors of creating a CNC machining part in a cost-effective price and fast lead time is that the designers can understand the possibility and limitation of CNC milling.

If the designer or engineer can design a part in a suitable for manufacturing process and bear in mind, design for manufacturing, the parts can be fabricated in the most optimal manufacturing way, by return, the cost and lead time will be reduced dramatically.

Take a very simple example, for the countersink holes, which are used for screw fitting. Normally, the holes dimension not need to be extremely precise and tolerance not be extremely tight. But you put the tolerance as +/-0.01mm. This will cost more CNC milling time and inspection time as more factors have to be taken into consideration during the production. This in the end will add up the final cost of the CNC milling parts.

Below are some design principles we think will affect the CNC milling and will help in the design for manufacturing in a certain way.
