Our SLA & SLS Service

1 to 3 days Delivery

WHAT IS SLA (SLS) ?

Stereolithography, usually known as SLA or SL, is one widely used industrial 3d printing technology. During SLA manufacturing process, the liquid resin is cured by the ultraviolet light and becomes solid layer and layer to form a model, rapid prototype or products to the desired shape in accurate geometries. SLA process is very fast and suitable for models with any structure.

What Parts are Suitable for SLA ( SLS)?

For prototypes or models which are small, light but complex in structure, SLA process might be the most suitable manufacturing process.



SLA prototypes are not as strong as CNC parts but some tiny features and complex structures can be made by SLA whilst CNC manufacturing cannot achieve.



SLA is a suitable process for making rapid prototypes that are used for geometry test, assembly test and demonstration and are needed urgently.

To learn more about our SLA ( SLS ) service, contact us now.

Advantages of SLA

1. The surface is smooth and of good quality.



2. The forming accuracy is high, with an accuracy of 0.1mm (the SLA accuracy in China is between 0.1-0.3mm, and there is great fluctuation);



3. Complex parts with very fine details and thin-wall structure can be made with high precision and easy to do post finish.



4. The processing cycle is short, generally about 1 to 3 days.

Disadvantages of SLA

1. The types of materials that can be selected are limited and must be photosensitive resin.



2. The strength of the processed materials is slightly poor, and it is not allowed to disassemble and screw for many times.

What Is SLS ?

Selective laser sintering (SLS) is a manufacturing technology that the powdered material is sintered and bonded by a laser to create a solid part out of a 3D model. The material typically is pure nylon or nylon glass filled. It is one of the most popular 3D printing technology to create a durable and strong part in very short time.

How Does SLS Work ?

A layer of powdered material is spreading on the upper surface of the formed parts. The control system controls the laser beam to scan on the powder layer according to the cross-sectional profile of the layer, when the temperature of the powdered material is heating to the melting point, the powdered material will be sintered and bonded, a layer is formed and finish.



After the completion of one layer, the worktable will drop by one layer, and the spreading roller will spread a layer of uniform and dense powder on it to sinter the section of a new layer until the whole model is completed and formed.



SLS technology opens up a way to quickly make all kinds of parts without any cutting tools, and provides a new manufacturing method for parts or molds which cannot be manufactured by other traditional production methods like CNC machining.

Request A Quote >

The Advantage of SLS

Support Any
Design Structure

Designers no need to worry too much about the structure and features. SLS is a 3d printing to allow the features are filled and form automatically with the powdered material built up. So design has very big freedom in design and not need to consider too much about the feasibility to manufacturing.

Fast Lead Time



SLS is one of the fast 3D printing manufacturing process. Simply the nylon or nylon glass filled material will be sintered. Unlike SLA or FDM, SLS does not need a separate feeder for support material. During sintering, unsintered powder will surround the parts at all times.

Strong and Durable



SLS Printing can print very strong and durable parts from strong layer adhesion, typically nylon, nylong glass filled. Therefore, SLS parts have very strong mechanical properties, like tesnsile strength, hardness, etc and can be used for mechanical test and evaluation.

Our SLA and SLS Capability

We can make parts by SLA and SLS with different material. Pls see below our SLA and SLS capability.

If you have any other special material request by SLA/SLS, please check with our project manager.

Material Type

Material

Code

 Process

 Color

Heat Deflection

 Temperature (HDT)

 Min

 Wallthickness

 Min Hole



Application



ABS Like

CUV9400E

SLA

White

40-50 ℃

0.6mm

1mm



■ Automotive

■ Medical

■ Consumer electronics etc

functional prototypes, water-resistant applications, appearance models with minimal finishing, durable concept models, high humidity environment applications and RTV patterns.



ABS/PBT

Like

SOMOS14120

SLA

Yellow

 40-50 ℃

0.6mm

1mm



■ Automotive

■ Medical

■ Consumer electronics etc

functional prototypes, water-resistant applications, appearance models with minimal finishing, durable concept models, high humidity environment applications and RTV patterns.



ABS Like

ABS LIKE

 watershed11122

SLA

Clear

40-50 ℃

0.6mm

1mm



■ Automotive

■ Medical

■ Consumer electronics etc

functional prototypes, water-resistant applications, appearance models with minimal finishing, durable concept models, high humidity environment applications and RTV patterns.



High

 tenacity

 ABS Like

ABS LIKE C-UV BESTY-1

SLA

Yellow

40-50 ℃

0.6mm

1mm



■ Automotive

■ Medical

■ Consumer electronics etc

functional prototypes, water-resistant applications, appearance models with minimal finishing, durable concept models, high humidity environment applications and RTV patterns.



Hight

 temperature

 resistant

 ABS like

YG-H3001

SLA

Grey

80-100℃

0.6mm

1mm



■ Automotive

■ Medical

■ Consumer electronics etc

functional prototypes, water-resistant applications, appearance models with minimal finishing, durable concept models, high humidity environment applications and RTV patterns.



Black Nylon

HP PA12

SLS

Black

95-150℃

0.5mm

1.2mm



■ Shell products;

■ automobile instrument panel and grid window;

■ assembly design;

■ functional prototype, etc



White Nylon



Precimid117X

Pro PA

SLS

White

120-150℃

0.5mm

1.2mm



Shell products;

■ automobile instrument panel and grid window;

■ assembly design;

■ functional prototype, etc



Nylon GB

 HP  PA12GB

SLS

Black

120-150℃

0.5mm

1.2mm



■Electric tool

■automobile industry

■machinery industry

■sports equipment

■ assembly design

■ functional prototype, etc



GET READY TO DISCUSS YOUR SLA/SLS PROJECT? CONTACT US NOW!
